Dual Roll Earlage Adapter for New Holland® Choppers | Kooima Ag
Kooima Ag
•
4m 11s
This adapter features an advanced crop flow system with an additional bottom intake roller, complementing the standard top roller. Specially engineered for higher horsepower harvesters and larger corn heads, the KFR920 delivers better cleanout, constant feeding, and increased harvesting speeds averaging 6-7 MPH.
The KFR920 header adapter is used for harvesting just the ears of corn while using a crop row header to make earlage. Earlage is harvested later than silage, giving the producer a longer working window and provides a product that reduces the amount of roughage that needs to be fed as compared to a corn-based ration.
The KFR920 will mount on the front of a New Holland® FR Series self-propelled forage harvester to facilitate the connection between the harvester and a crop row header. It is ideally suited for 10 to 12 row corn heads and fits both narrow and wide row heads. The design and feeding angle promote faster product feeding when harvesting. Forage harvester will need dual drive hook ups to power various corn heads, including John Deere®, New Holland®, Case IH®, Drago™, and more. Conversation brackets for Case IH® or New Holland® Corn Heads K98CJD, and K4000CH. Conversion bracket for Geringhoff® KGCKIT.
Installation of the KFR920 Header Adapter is the same as hooking up any other implement; you can leave the adapter on the harvester or corn head when not in use. When leaving the adapter on the corn head, it's simply picking up the adapter/corn head and hooking up the PTOs.
https://www.kooimaag.com/products/new-holland-double-roll-adapter
Up Next in Kooima Ag
-
Single Roll vs Dual Roll Earlage Adap...
Our single roll adapter did a nice 4.2 mph in the field, with our dual roll, we could get up to 6 mph in the same field/conditions. Our K00494 Single Roll adapter is ideal to use in 600 horsepower or less machines for a midsize operation. Our K00498 Dual Roll Adapter is made for higher horsepow...
-
The Importance of Upper Rear Feed Rol...
Shop upper rear feed rolls here: https://www.kooimaag.com/products/upper-rear-feed-roll-7
-
Bale Ripper Installation for Mixer Wa...
If you put full complete round bales in your mixer wagon, this bale ripper kit results in less time processing the bale. We have seen consistent 15-20 minutes of mixing time shaved off of each bale, as the bale gets brought down into the knives faster. We have also seen less fuel and less wear an...
